DF5-Pro
The DF5-Pro is a low altitude security system that uses Cognitive Radio Protocol Cracking(CRPC) technology to solve the detection, identification and positioning of the civil drones.The system supports passive detection, precise identification, identify friend and foe, and provide early warning and prediction for unmanned aerial vehicles in protected areas, with optional direction-finding functions as needed.
Featured
Environmentally Safe
By adopting passive detection technology, there is no influence or disruption on the surrounding environment
Full-Covered Drone Library
Support various types of drone brands, FPV drones,Wi-Fi drones, DIY drones, etc. Cover more than 98% of the drones on the market
Highly Integrated
All modules are integrated into a protective dome
Good Scalability
It can be used in integration with radar, electro-optical, and other jamming systems
Networking Positioning
By using a single device, accurate direction finding can be accomplished. By using multiple devices, networking-based positioning can be achieved, and the distance can be extended infinitely
Strong Flexibility
It has strong mobility in transportation and deployment
Specifications
| Performance Indicators | Detection Bands | 30MHz~6GHz |
| Detection Distance | 0~5km
(Differences exist due to different environments and drone types) |
|
| Detection Range | 360° Full Airspace | |
| Detection Quantity | >35 Drones (Simultaneous) | |
| Position Accuracy | ≤10m (RMS) | |
| Detection Finding Accuracy | (RMS) 3° (hovering), 10° (moving) | |
| Physical Indicators | Power Supply | AC110~240V |
| Power Consumption | ≤60W | |
| Dimensions | φ346mm × 514.5mm (±2mm) | |
| Weight | ≤9kg | |
| IP Rating | IP66 |
1. Product Profile
The system adopts an integrated design, which features high integration, good scalability, and strong adaptability. It can be organically integrated with other security systems and is suitable for long-term protection in diverse sectors, including:
-
Public Safety & Correctional Facilities
-
Aviation (Airports)
-
Sports Venues (Stadiums)
-
Critical Infrastructure (Water Conservancy and Hydropower)
2. Key Features
-
Environmentally Safe: By adopting passive detection technology, the system operates with zero influence or disruption to the surrounding electromagnetic environment.
-
Full-Covered Drone Library: Supports a wide range of drone brands, including FPV drones, Wi-Fi drones, and DIY drones, covering more than 98% of the drones on the market.
-
Highly Integrated: All core modules are integrated into a single, professional protective dome.
-
Good Scalability: Designed for seamless integration with radar, electro-optical (EO/IR) sensors, and active jamming systems.
-
Networking Positioning: * Single Device: Accomplishes accurate direction finding.
-
Multi-Device: Achieves networked positioning with the ability to extend coverage distance infinitely through system scaling.
-
-
Strong Flexibility: Features high mobility for rapid transportation and ease of deployment.
