CB MICRO 1S1N
CB_MICRO_1S1N_P0 is a high-performance carrier with a compact design that can carry one NX board and one 9364SOM board. It integrates detection, direction-finding, jamming and spoofing functions into a single system and has multiple interfaces, such as one gigabit Ethernet port, one Type-C port, one USB2.0 port, one SIM card slot, one M.2(2230) port for SSD, one mini PCIE (supports 4G), an adjustable speed fan and power interface, two RS232 ports, one I2C port, one vibration motor and buzzer interface, and one 485 port, etc.
CB_MICRO_1S1N_P0 has detection, direction-finding, jamming, and spoofing functions, and can be used in various products.
Featured
Ultra-Compact Carrier Design
A high-performance, space-efficient carrier board capable of hosting one NX board and one 9364 SOM board simultaneously, ideal for size-constrained deployments.
All-in-One C-UAS Integration
Integrates detection, direction-finding, jamming, and spoofing into a single unified system, eliminating the need for separate hardware modules.
Versatile Product Compatibility
Designed as a universal platform, the board can be deployed across a wide range of counter-UAS products and configurations.
Rich I/O Interfaces
Equipped with a comprehensive set of ports including Gigabit Ethernet, Type-C, USB 2.0, mini PCIe (4G support), M.2 (2230) SSD, RS232, I2C, and RS485, enabling flexible peripheral expansion.
Built-In Connectivity Options
Features a dedicated SIM card slot and mini PCIe 4G support for standalone mobile or remote-network operation without external adapters.
Active Thermal & Alert Management
Includes an adjustable-speed fan, vibration motor, and buzzer interface, ensuring reliable thermal control and operator awareness in field conditions.
Specifications
| Power | 12V Power, supports 6~24V wide voltage input, XT30 interface function |
| Dimensions | 116mm * 65mm |
| Power Consumption | ≤36W |
| Operating Temperature | -25°C to 65°C |
| Ethernet | SM08B Port supports Gigabit |
| USB | One Type-C, and one USB2.0 with BM04M port |
| RS232 | Two RS232 Ports |
| Debugging | A2001WRS-3P |
| M.2 | One M.2 port supports NVME protocol, the size is 2230 |
| Mini PCI-E | Install 4G Module |
CB_MICRO_1S1N_P0 is a high-performance carrier with a compact design that can carry one NX board and one 9364SOM board. It integrates detection, direction-finding, jamming and spoofing functions into a single system and has multiple interfaces, such as one gigabit Ethernet port, one Type-C port, one USB2.0 port, one SIM card slot, one M.2(2230) port for SSD, one mini PCIE (supports 4G), an adjustable speed fan and power interface, two RS232 ports, one I2C port, one vibration motor and buzzer interface, and one 485 port, etc.
CB_MICRO_1S1N_P0 has detection, direction-finding, jamming, and spoofing functions, and can be used in various products.
| Interface | Connector Type/
Plug Model |
Specifications | ||||||||||||||||||
| Electrical Compass | SM04B/GHR04V-S |
|
||||||||||||||||||
| Adjustable Speed Fan | BM04B/GHR04V-S |
|
||||||||||||||||||
| Power ON/OFF and Indicator | BM06B/GHR06V-S |
|
||||||||||||||||||
| USB2.0 | BM04B/GHR04V-S | / | ||||||||||||||||||
| Buzzer and Vibration Motor | BM06B/GHR06V-S | / | ||||||||||||||||||
| 485 Port | SM02B/GHR02V-S |
|
||||||||||||||||||
| 1.5GHz Power Amplifier Control | BM04B/GHR04V-S |
|
